0.5mm 3732 Black Silicone Rubber Coated Fiberglass Cloth For Fabric Expansion Joint

Name: 05mm 3732 Black Silicone Rubber Coated Fiberglass Cloth For Fabric Expansion Joint
Brand: Unionfull
Price: 2.5 USD

Wholesale 0.5mm 3732 Black Silicone Rubber Coated Fiberglass Cloth For Fabric Expansion Joint from china suppliers

Brand Name : Unionfull

Model Number : UPSE-8732S80

Certification : ISO9001:2008, SGS;TUV

Place of Origin : China

MOQ : 500 Meters

Price : $2.5-3.5/ Square Meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 50000 square meters per day

Delivery Time : 15 Working Days After Receiving Payment

Packaging Details : 50 meters per roll with poly bag

Base Cloth : 3732 Fiberglass Fabric

Coating : Black Silicone, 80g/m2 on single side

Total Thickness : 0.5mm

Weight : 430g/m2+80g/m2

Width : 100cm

Feature : Thermal Insulation, Flexibility

Weave : 8H Satin

Keyword : black silicone coated fiberglass fabric

Contact Now

0.5mm 3732 Black Silicone Coated Fiberglass Cloth For Fabric Expansion Joint

Silicone coated glassfiber fabrics for industrial insulation and fire/smoke protection are made from alkali -free E-glass fiber yarns which loomstate fabric can resist 550°C/1022°F. For the production of silicone coated fiberglass fabric, the glass yarns is in a filament diameter of 9 µm. Then it has been coated or impregnated with a black silicone/rubber on one side or both sides. This rubber coated fiber glass fabric is very flexible but also high strength. It combines the high strength of e-glass fiber glass cloth and chemical resistance of silicone coating, which make the coated cloth have advantages such as stable dimension, tear resistance and electrical insulation.

The uncoated basic fiberglass fabric 3732 can resist temperature below 550℃. But the rubber/silicone coating can resist 260 degree Celsius. And base on the features of silicone coating and basic fiberglass fabric, application of silicone coated fiberglass cloth are mainly for thermal insulation and electrical insulation, such as fire blankets/curtains/gloves, fabric expansion joints, thermal insulation exhaust blanket for pump/pipeline and other fire fighting equipments.

Specification Of UPSE-8732S80:

Item	Silicone Coated Fiberglass Fabric
Material	E-glass Fiber Glass
Weave	8H Satin
Warp Density	20 Ends/CM
Weft Density	11 Ends/CM
Mass Per Unit	510g/m2(430+80)
Coating	Black silicone, 80g/m2
Thickness	0.5mm
Width	100cm
Working Temperature	Silicone Coating below 260℃

Features:

Fireproof, thermal insulation
Anti chemical agents, acid and alkali
Water and oil proof.
Dimension stability
High tensile strength, durable
Abrasion corrosion resistance
Electric insulation
Service temperature from -50℃ to 260℃

Application:

Depending on the various application, silicone coated fabrics have different thickness. This 0.5mm silicone coated material is suitable for fire/smoke protection and thermal/acoustic insulation in most field

Power heat/electrical insulation blanket
Automotive heat protection
Metal and aviation industries, welding blanket
Shipbuilding cover
Construction electrical protection cover

Picture:

0.5mm 3732 Black Silicone Rubber Coated Fiberglass Cloth For Fabric Expansion Joint
